Tp-link Usa Corporation
TP-Link Omada EAP225 wireless access point 1350 Mbit/s White Power over Ethernet (PoE)
TP-Link Omada EAP225 wireless access point 1350 Mbit/s White Power over Ethernet (PoE)
Regular price
$60.99 USD
Regular price
Sale price
$60.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
TP-Link Omada EAP225 wireless access point 1350 Mbit/s White Power over Ethernet (PoE)
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate | 1350 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 450 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af |
| Cabling technology | 10/100/1000Base-T(X) |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| VLAN support | Yes |
| Virtual LAN features | VLAN mapping |
| Rate limiting | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Quality of Service (QoS) support | Yes |
Shipping & Returns
Shipping & Returns
In-stock items ship within 1–2 business days. Free shipping on orders over $500. 30-day return policy — see our returns page for details.
Share
Specifications
Specifications
General
| 2.4 GHz | Yes |
|---|---|
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate | 1350 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 450 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af |
| Cabling technology | 10/100/1000Base-T(X) |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| VLAN support | Yes |
| Virtual LAN features | VLAN mapping |
| Rate limiting | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Quality of Service (QoS) support | Yes |
| BeamForming | Yes |
| Transmitting power (CE) | 23 dBm |
| Transmitting power (FCC) | 24 dBm |
General
| Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK |
|---|---|
| MAC address filtering | Yes |
| Service Set Identifier (SSID) features | Multiple SSIDs |
| Number of SSID supported | 16 |
| Access Control List (ACL) | Yes |
General
| Web-based management | Yes |
|---|---|
| Syslog | Yes |
General
| Ethernet LAN (RJ-45) ports | 1 |
|---|---|
| DC-in jack | Yes |
General
| Power over Ethernet (PoE) | Yes |
|---|---|
| Power over Ethernet (PoE) type supported | Passive PoE |
| Output voltage | 12 V |
| Output current | 1.5 A |
| Power consumption (typical) | 10.15 W |
General
| Placement | Ceiling, Wall |
|---|---|
| Product colour | White |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| On/off switch | Yes |
| Reset button | Yes |
| LED indicators | Power, WLAN |
General
| Antenna type | Internal |
|---|---|
| Antenna direction type | Omni-directional |
| Antenna features | Integrated antenna |
| Antennas quantity | 5 |
| Antenna gain level (max) | 5 dBi |
General
| Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux |
|---|
General
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
|---|
General
| SIM card slot | No |
|---|
General
| Width | 205.5 mm |
|---|---|
| Depth | 181.5 mm |
| Height | 37.1 mm |
General
| Package width | 228 mm |
|---|---|
| Package depth | 340 mm |
| Package height | 65 mm |
| Package weight | 910 g |
| Package type | Box |
General
| Quantity per pack | 1 pc(s) |
|---|---|
| AC adapter included | Yes |
| PoE adapter included | Yes |
| Mounting kit | Yes |
| Quick start guide | Yes |
General
| Operating relative humidity (H-H) | 10 - 90% |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
General
| Sustainability compliance | Yes |
|---|
General
| Harmonized System (HS) code | 85176990 |
|---|
